Wylex NHSPSF63 63A 1P+N Fuse Combination Unit c/w Fuses

Name: Wylex NHSPSF63 63A 1P+N Fuse Combination Unit c/w Fuses
Brand: Wylex
SKU: NHSPSF63
Price: 184.0 GBP
Availability: InStock

SKU NHSPSF63

£184.00 - £184.00

£184.00 inc VAT £153.33 exc VAT

£184.00 - £184.00

£184.00 inc VAT £153.33 exc VAT inc VAT £153.33 exc VAT

Availability:

9 in stock, ready to be shipped

Quantity

Estimated delivery time: 3-4 working days

Description

Wylex NHSPSF63 NH 63A 1P+N Fuse Combination Unit is a high-capacity solution for circuit protection in demanding commercial and industrial environments. Housed in a RAL 7035 painted steel enclosure, this IP40 rated fuse unit includes a 63A fuse (Shape A2/A3) and supports cable spreading room up to 70mm². Designed for safe circuit isolation, it features a padlockable operating handle, a reversible front door with 180° opening, and full compliance with BS EN 60947-3, IEC 60947-3, and BS EN 61439-3 standards. With a rated operational power of 18.5kW at 400V, the Wylex NHSPSF63 is ideal for electricians and contractors seeking reliable NH series fuse combination units.

Specification

Version as main switch Yes
Version as safety switch No
Max. rated operation voltage Ue AC 230 V
Rated permanent current Iu 63 A
Rated operation power at AC-23, 400 V 18.5 kW
Conditioned rated short-circuit current Iq 50 kA
Rated short-time withstand current lcw 1.5 kA
Suitable for fuses Shape A2/A3
Number of poles 1
With error protection No
Type of electrical connection of main circuit Cable clamp
Equipped with connectors Yes
Suitable for floor mounting No
Suitable for front mounting No
Suitable for busbar mounting No
Type of control element Door coupling rotary drive
Position control element Front side
Motor drive optional No
Motor drive integrated No
Version as emergency stop installation No
Degree of protection (IP), front side IP40
Product Standard/s BSEN60947-3, IEC60947-3,
BSEN61439-3
Terminal Capacity L&N 25 mm²
Frequency 50 - 60 Hz
CE Conformity Yes
WEEE Symbol Yes
UKCA Conformity Yes
