Schneider A9D31810 10A 30MA TYPE B RCBO 10KA Acti9
SKUA9D31810
Original price
£65.00
-
Original price
£65.00
Original price
£65.00inc VAT£54.17exc VAT
£65.00
-
£65.00
Current price£65.00inc VAT£54.17exc VATinc VAT£54.17exc VAT
| /
Availability:
26 in stock, ready to be shipped
Estimated delivery time: Next working day
Description
The Schneider Electric A9D31810 is a high‑performance earth leakage circuit breaker with overcurrent protection (RCBO) designed for dependable electrical safety in commercial and residential distribution boards. This 1P+N RCBO combines reliable 10 A B‑curve tripping with 30 mA earth‑leakage sensitivity to protect circuits from overloads, short circuits and hazardous leakage currents — reducing the risk of electric shock and fire.
Part of the trusted Acti9 iC60H range, the A9D31810 RCBO features instantaneous residual current protection (Type A) and a high 10 kA breaking capacity at 240 V AC, meeting stringent safety standards including IEC 61009‑1 and IEC 61009‑2‑2. Its compact 1‑module DIN rail design and reliable thermal‑magnetic trip unit make it ideal for final circuits in homes, offices, retail and light industrial environments.
Specification
Range - Acti9
Poles description - 1P + Ns
Earthing system - TN
Curve code - B
Earth-leakage sensitivity - 30mA
Breaking capacity - 10000 A Icn at 230/240 V AC 50/60 Hz
Neutral position - Left
Neutral position - 1
Device location in system - Outgoer
Network frequency - 50 Hz
Network type - AC
Trip unit technology - Thermal-magnetic
[Ue] rated operational voltage - 230/240 V AC 50/60 Hz
Residual current tripping technology - Voltage dependent
Earth-leakage protection class - Type A
Limitation class - 3
[Ui] rated insulation voltage - 400 V AC 50/60 Hz
Surge current - 250A
[Uimp] rated impulse withstand voltage - 4 kV
Suitability for isolation - Yes
Contact position indicator - Yes
Mounting support - DIN rail
Mounting mode - Clip-on
Comb busbar and distribution block compatibility - No
