Kosnic UEM04/ST UEM Pro Self-Test 4W Universal Emergency Module

SKU UEM04/ST
Original price £41.88 - Original price £41.88
Original price
£41.88 inc VAT £34.90 exc VAT
£41.88 - £41.88
Current price £41.88 inc VAT £34.90 exc VAT inc VAT £34.90 exc VAT

Estimated delivery time: Next working day

Description
  • Standard/Self-test
  • Built-in loop-in loop-out terminals for 2 x 3-core cables
  • Built-in cable clamp, push to release
  • Loop-in and loop-out push-wire terminals
  • Built-in self-test function according to BS-EN-62034-2012
  • Designed for use with all LED luminaires (class III) with external driver
  • Easy Plug & Play installation
  • For maintained or non-maintained emergency lighting systems
  • Internal Li-ion battery with improved lifespan
  • Easy battery replacement

The Universal Emergency Module (UEM) with available Automatic Self-Test (AST) version is suitable for class III luminaires with integrated LEDs and separate LED drivers. Provides an operation time of three hours. The UEM can be installed within a luminaire or within the ceiling void.

Specification
  • Input Voltage - 220-240 Vac 50-60 Hz
  • Output Wattage (W) - 4.8
  • Output Voltage - 15-58 Vdc
  • Output Current (mA) - 40-140
  • Protection - IP20
  • Battery - Li-Ion KBAT2600
  • Battery Voltage - 7.4V
  • Battery Capacity - 2600mAh
  • Charging Time - 24H
  • Test Function - Manual and Automatic
  • Input Connection - Push-fit terminals 0.5-1.5 mm2

Datasheet
