Collingwood EUP30T1HMC0 30W 750mA Trailing-Edge Dimmable LED Panel Driver
Estimated delivery time: Estimated delivery tomorrow*
Description
The Collingwood EUP30T1HMC0 is a 30W constant-current LED driver designed to power compatible Collingwood LED panels. It provides a fixed 750mA output and supports trailing-edge mains dimming, allowing compatible panel lighting to be smoothly adjusted using a suitable LED dimmer.
A 220–240V AC input is converted to a 3–40V DC constant-current output, with a maximum rated power of 30W. The plug-and-play connection helps reduce installation time when used with the appropriate Collingwood panel.
The IP20 rating makes this driver suitable for dry indoor applications such as offices, classrooms, meeting rooms and commercial interiors. It operates across an ambient temperature range of -20°C to 50°C and provides a power factor of 0.9.
Input and output connections accept conductors between 0.75mm² and 2.5mm². The driver is also listed with the Collingwood LEDEP10 emergency converter as a compatible accessory for suitable emergency-lighting projects.
Always confirm the luminaire’s required current, operating-voltage range and power before using this driver as a replacement.
