Click Scolmore MCP595 13A 1 Gang Switched Socket Outlet With Twin Type C USB (4A) Outlets

The Click Scolmore MCP595 is a dusty grey 13A one-gang switched socket with integrated USB Type-A and USB Type-C charging outlets. It provides 5V DC USB charging, three-pin safety shutters, twin-earth terminals and a supplied 40mm-deep metal back box.

What is the Click Scolmore MCP595?

The MCP595 is a 13A one-gang switched socket outlet from the Click Scolmore Metal Clad Pro range. It combines one UK mains socket with USB Type-A and USB Type-C charging outlets in a dusty grey metal accessory.

Which USB connections does the MCP595 provide?

The MCP595 provides one USB Type-A connection and one USB Type-C connection. These allow compatible devices to be charged without using a separate plug-in USB adaptor.

What is the USB charging output?

Scolmore specifies 5V DC independent charging, with the Type-A port rated up to 2.4A and the Type-C port rated up to 3A. The detailed feature list states a 4.2A charging capacity.

Does the USB-C port support Power Delivery?

The official MCP595 specification lists a standard 5V DC USB-C charging output but does not state that USB Power Delivery or higher-voltage rapid charging is supported. Compatibility and charging speed will depend on the connected device and cable.

Can both USB ports be used at the same time?

The product provides both Type-A and Type-C charging outlets. Available charging current may be shared or limited when multiple devices are connected, so charging speed can depend on the connected equipment.

Can I use the 13A socket while charging a USB device?

The mains socket and USB charging connections are integrated into the same accessory. Compatible equipment may be connected to the socket while a USB device is charging, provided the circuit and accessory ratings are not exceeded.

Does the MCP595 have safety shutters?

Yes. The 13A socket has three-pin safety shutters. All three pins of a correctly inserted UK plug must engage before the shutters open.

Is a back box included?

Yes. The MCP595 is supplied with a matching 40mm-deep metal surface back box.

Is the MCP595 suitable for surface mounting?

Yes. The included metal back box makes it suitable for surface-mounted indoor installations.

Does the MCP595 have twin-earth terminals?

Yes. Twin-earth terminals are provided to support protective-conductor termination and earth continuity.

What cable sizes can the terminals accept?

The terminal capacity is up to three 2.5mm² conductors or two 4mm² conductors, subject to the installation and circuit requirements.
