BG Nexus Storm WP55ARCD 13A Type A RCD Fused Spur Weatherproof

BG Nexus Storm WP55ARCD 13A Type A RCD Fused Spur Weatherproof

SKU WP55ARCD
£23.00 - £23.00
£23.00 inc VAT £19.17 exc VAT
£23.00 - £23.00
£23.00 inc VAT £19.17 exc VAT inc VAT £19.17 exc VAT
Availability:
Only 1 left!

Estimated delivery time: 3-4 days

Description

 Main Features:

  • IP66 rated when in use
  • Type A RCD protection: Cuts off power safely & prevents
    electrocution in event of a fault 30mA trip current & 40ms trip circuit operation.
  • Latching operation: socket returns to original state when power is resumed
  • Angled colour coded terminals with captive screws
  • Flexible membrane: Allows easy switch and power status indication without compromising IP rating
  • Hinged cover with fixing screw provides access to the fuse
  • Fast fix - no separate screws, no screw covers, 150º rotation
  • Multiple gland entry positions: 5 versatile entry options with M25
    capability with an easy push out blank plug design. 1 drill out
    entry 20/25mm in rear face
Specification
  • Standard(s) - BS7288
  • Rating - 13 Amp 250V AC
  • Max Load - 3,120 Watts
  • RCD Mechanism – Latching (Passive) - Socket returns to original state when power is resumed
  • RCD Type - A
  • Trip Current -30mA, 40mS trip speed
  • Terminal Capacity - 3 x 2.5mm2
    , 2 x 4.0mm2 , 1 x 6.0mm2
  • IP Rating - IP66
  • RoHS Directive - Yes
  • WEEE Directive - Yes
  • Number of cable entries - 5 x 20mm. 1 in each of 3 sides and 2 in the remaining side 1 drill out entry
    20/25mm in rear face
Product Dimensions
  • Packed Height (mm) 147
  • Packed Width (mm) 122
  • Packed Depth (mm) 72
