BG Storm WP53 Weatherproof 13 Amp Switched Fused Connection Unit

BG Storm WP53 Weatherproof 13 Amp Switched Fused Connection Unit

SKU WP53
Sold out
£12.78 - £12.78
£12.78 inc VAT £10.65 exc VAT
£12.78 - £12.78
£12.78 inc VAT £10.65 exc VAT inc VAT £10.65 exc VAT
Availability:
Out of stock

Estimated delivery time: Estimated delivery tomorrow*

Description

BG Nexus Storm WP53 IP66 13A SW Fused Connection Unit. Features an angled colour coded terminals with captive screws and visible indication of power status through see-through cover.

Main Features:

  • IP66 rated when in use
  • Angled colour coded terminals with captive screws
  • Flexible membrane: Allows easy switch and power status indication without compromising IP rating
  • Hinged cover with fixing screw provides access to the fuse
  • Fast fix - no separate screws, no screw covers, 150º rotation
  • Multiple gland entry positions: 5 versatile entry options with M25 capability with an easy push out blank plug design. 1 drill out entry 20/25mm in rear face
Specification
  • Standard(s) - BS 1363-4
  • Rating - 3,120 Watts Max, 13Amp 250V AC
  • Terminal Capacity - 3 x 2.5mm², 2 x 4.0mm² & 1 x 6.0mm²
  • Switch Type - Double Pole
  • IP Rating - IP66
  • RoHS Directive - Yes
  • WEEE Directive - Yes

Datasheet






Product Dimensions

Width (mm) - 115.4

Height (mm) - 136.7
