BG Evolve PCDMB42B 2G 2W 20A Switch Matt Black

BG Evolve PCDMB42B 2G 2W 20A Switch Matt Black

SKU PCDMB42B
£4.86 - £4.86
£4.86 inc VAT £4.05 exc VAT
£4.86 - £4.86
£4.86 inc VAT £4.05 exc VAT inc VAT £4.05 exc VAT
Availability:
944 in stock, ready to be shipped

Estimated delivery time: Estimated delivery tomorrow*

Description

Main Features:

  • Easy to install, supplied with fixing screws and installation instructions
  • 2 way switching allows for a second switch position in a circuit
  • Captive backed out terminal screws for fast installation and to prevent screw loss
  • Screwless front plate clips on and off easily, ideal for redecorating
Specification

Standard(s) - BS EN 60669-1
Rating - 20 Amp, 16AX inductive rated
Voltage - 250V AC
Terminal Capacity - 4 x 1mm² 4 x 1.5mm² 2 x 2.5mm² & 1 x 4.0mm²
RoHS Directive - Yes
WEEE Directive - Yes
Mounting Box Depth (Min) - 25mm

Datasheet

Product Dimensions

  • Width (mm) - 86
  • Height (mm) - 86
