Ansell AAZT5/SYM/1 Aztec 5 240W Symmetric Floodlight

Ansell AAZT5/SYM/1 Aztec 5 240W CCT Selectable Symmetrical LED Floodlight

The Ansell AAZT5/SYM/1 Aztec 5 is a powerful 240W commercial LED floodlight engineered for demanding industrial, commercial and coastal lighting installations. Producing up to 44,000 lumens at 4000K, this high-output floodlight provides bright, wide-area illumination for large outdoor spaces where dependable performance, energy efficiency and durability are essential.

Its broad 110-degree symmetrical beam distributes light evenly across open areas, making the Ansell Aztec 5 an excellent choice for warehouse yards, loading bays, car parks, service areas, commercial premises, industrial sites and large building exteriors. Unlike an asymmetric floodlight designed to direct light primarily forwards, this symmetrical model spreads illumination more evenly around the fitting.

Selectable 3000K, 4000K and 5000K colour temperature

The AAZT5/SYM/1 features selectable colour temperature, allowing the installer to choose between:

• 3000K warm white for softer exterior illumination
• 4000K cool white for clear, practical commercial lighting
• 5000K daylight white for bright industrial and security applications

This CCT-selectable design reduces the need to stock separate floodlights for different projects and allows the final light colour to be selected during installation. It gives electrical contractors greater flexibility when lighting warehouses, industrial units, coastal buildings, car parks and commercial outdoor areas.

High-output, energy-efficient commercial floodlighting

Delivering up to 44,000 lumens from 240W, the Ansell Aztec 5 offers an efficacy of up to 180 lumens per watt. This makes it a strong replacement option for older, less efficient high-wattage exterior floodlights used across industrial and commercial properties.

The powerful LED output can help provide effective illumination across large spaces while reducing the energy demand and maintenance requirements associated with traditional discharge lighting. The integrated LED light source is rated to L80 100,000 hours, supporting long-term use in installations where access and maintenance can be difficult or expensive.

Integrated photocell for automatic dusk-to-dawn control

An integral photocell allows the floodlight to operate automatically according to surrounding daylight levels. Two lux settings and an off option provide additional control, allowing the installer to configure the fitting for the requirements of the site.

Automatic photocell operation is particularly useful for security lighting, perimeter lighting, building exteriors, loading areas and commercial yards that require illumination after dark without relying on manual switching.

Marine-grade construction for harsh environments

The Ansell AAZT5/SYM/1 is manufactured from high-performance die-cast aluminium with marine-grade construction. It is designed for challenging commercial, industrial and coastal environments, including locations exposed to adverse weather and corrosive conditions.

Its robust construction makes the Aztec range suitable for coastal properties, swimming-pool environments, chemical plants, industrial facilities and other demanding outdoor applications where a standard exterior floodlight may not provide sufficient durability.

IP66 weatherproof and IK08 impact resistant

With an IP66 ingress-protection rating, the Aztec 5 is protected against dust and powerful water jets, making it suitable for permanent outdoor installation. The IK08 impact rating provides additional resistance to accidental knocks and physical impact.

These protective ratings make the AAZT5/SYM/1 a dependable option for exposed locations such as:

• Industrial yards and loading bays
• Warehouse exteriors
• Commercial car parks
• Coastal buildings
• Manufacturing facilities
• Service and storage areas
• Building perimeters
• Large outdoor workspaces

The floodlight is designed to operate in temperatures as low as -30°C, supporting reliable performance throughout demanding seasonal and environmental conditions.
